We are a professional Swiss Type CNC automatic lathe company. We specialize in producing varied precision parts of automobiles, motorcycles, bikes, pneumatic tools, optics, electronic equipments, pedicle screw, poly-axial pedicle screw-U head(poly-axial pedicle screw-headbody), poly-axial pedicle screw-Reduction headbody ( poly-axial pedicle screw-long arm head), cortical screw, dental screw, medical Instrument, shafts etc. |
| |
| Please kindly refer to the following as our brief introduction： |
| |
| Production Equipments: |
Japan Nomura Swiss Type CNC Automatic Lathe (multi-function with sub-spindle operations, including turning, milling and cross drilling.)
‧NN-16SB6* 1Set: Work Size (Max.) O.D. 16.0mm
‧NN-20UB7* 1Set: Work Size (Max.) O.D. 20.0mm
‧NN-20J* 1Set: Work Size (Max.) O.D. 20.0mm
‧NN-20J2* 1Set: Work Size (Max.) O.D. 20.0mm
‧NN-25UB7* 1Set: Work Size (Max.) O.D. 25.0mm
‧NN-25UB8* 2Set: Work Size (Max.) O.D. 25.0mm
‧NN-32YB* 2Set: Work Size (Max.) O.D. 32.0mm
‧NN-32YB II* 2Set: Work Size (Max.) O.D. 32.0mm
‧NN-32YB GL* 1Set: Work Size (Max.) O.D. 32.0mm
All of The Swiss Type CNC Automatic Lathes are with front / back main spindles and milling function. They are also available to do eccentricity processing. |
| |
Processing Capability:
|
| 1. |
| Range of outer diameter: |
 |
0.5mm - |
|
32.0mm. |
|
| 2. |
Materials: stainless steel (SUS303/ SUS304/ SUS316/ SUS416/ SUS420/ SUS630), free cutting steel (1144/1215/12L14), alloy steel (SNCM220/ SCM440/SCM415/ SNCM439), carbon steel (S45C), bearing steel (SUJ2), die steel (SKD11), aluminum alloy (AL6061-T6/ AL7075-T6), titanium alloy (Gr.5/ Gr.4/ Gr.2), PTEF, POM, PEEK, ABS etc. |
|
| |
Peripherals Equipments:
|
| 1. |
Table Lathe： Working size(Max.) O.D. 32.0mm. |
| 2. |
Table Lathe： Working size(Max.) O.D. 15.0mm. |
| 3. |
Precision Carbide Tool Grinding and Lapping Machine. |
| 4. |
sPINner HD735 Magnetic Deburring & Polishing Machine：
* Designed for large quantity of parts.
* Fully automatic. One person can run multiple machines.
* Suitable for all types of metal parts. |
|
| |
Inspection Equipments:
|
| 1. |
Micro-Vu (U.S.A.) Vertex 420 Measuring Center (CNC 2.5D Image Measuring System)
measuring volume:
‧ 300mm*300mm*150mm
‧ XY repeatability 2.6μm
‧ Z Repeatability 3.0μm |
| 2. |
ARCS (Taiwan) 2.5D Measurement System.
measuring volume：
‧ 300mm*200mm*200mm
‧ XY repeatability (3+L/150)μm |
| 3. |
Mitutoyo (Japan) Roughness Tester(SJ-401). |
| 4. |
Sylvac (Swiss) Digital Height Gage (0.0 – 200.0mm / accuracy 1.0μm). |
| 5. |
Mitutoyo (Japan) Caliper & Micrometer:
Mechanical & digital type. |
| 6. |
TESA (Swiss) Caliper & Micrometer:
Mechanical & digital type. |
| 7. |
Taiwan KKS/ KGS/ OSG Thread Gauge & Ring Gauge. |
| 8. |
Vermont (U.S.A.) Pin Gauge： (Ø0.2 - Ø10.0mm / accuracy 0.01mm ). |
| 9. |
BOWERS(U.K.) XT Holematic Digital Pistol-grip Bore Gauges(Ø2.0 – Ø50.0mm / accuracy 0.001mm ). |
|
| |
 |
| |
Please contact us for more information: |
| |
Giant Pro Precision Industrial Co., Ltd. |
| Address: |
No.1, Ln. 29, Zhongxiao St., Wuqi Dist., Taichung City 435, Taiwan |
| VAT No.: |
28809047 |
| Contact Person: |
Martin Chi |
| Tel: |
+886-4-2656-0639 |
| Fax: |
+886-4-2656-0620 |
| Mobile: |
0937-338991 |
| E-Mail: |
giant.pro2008@gmail.com / sales@giant-pro.com |
|
|
|
|
|
